2022 Dynamax Isata 5 Series 30FW

Type
Class C
MSRP
$236,158.00
Compare with another RV

Specs

Engine Brand Name
Cummins
Engine Type
I6
Cylinders
6
Horsepower (bhp/kW)
360 / 268.6
Torque (Ft Lbs/Nm)
800 / 1084.6
Fuel Requirements
Regular
Fuel Type
Diesel
Turbocharged
Yes
Supercharged
No
Chassis Model
5500
Chassis Brand
Ram
Displacement (l)
6.7
Carburetion Type
Fuel Injected
Transmission Type
Automatic
Number Of Speeds
6
Overdrive
Yes
Transmission Brand
AISIN®
Wheels Composition
Aluminum
Front Wheel Width (in)
6
Rear Wheel Width (in)
6
Number Of Axles
1
Front Tire (Full Spec)
225/70R 19.5G BSW AS
Rear Tire (Full Spec)
225/70R 19.5G BSW AS
Front Brake Type
Hydraulic Disc
Rear Brake Type
Hydraulic Disc
Anti-Lock Brakes
Standard
Exhaust Brake
Standard
Length (ft/m)
32.08 / 9.8
Width (in/mm)
96 / 2438.4
Height (in/mm)
148 / 3759.2
Wheelbase (in/mm)
237.5 / 6032.5
Interior Height (in/mm)
82 / 2082.8
Length (ft/ft)
32
Length (ft/in)
1
Dry Weight (lbs/kg)
16856 / 7645.9
Towing Capacity (lbs/kgs)
10000 / 4536
GVWR (lbs/kgs)
19500 / 8845.2
Fuel Capacity (gal/l)
52 / 196.8
Number Of Fresh Water Holding Tanks
1
Total Fresh Water Tank Capacity (gal/l)
78 / 295.3
Number Of Gray Water Holding Tanks
1
Total Gray Water Tank Capacity (gal/l)
45 / 170.3
Number Of Black Water Holding Tanks
1
Total Black Water Tank Capacity (gal/l)
45 / 170.3
Propane Tank (s)
Standard
Number Of Propane Tanks
1
Total Propane Tank Capacity (gal/lbs)
20.3 / 86
Seat Type
Bucket
Seat Material
Vinyl
Power Adjustable Seat
Yes
Reclining Seats
Yes
Swivel Seats
No
Seat Armrests
Yes
Number Of Seats
2
Number Of Rows
1
Body Material
Aluminum
Sidewall Construction
Fiberglass
Number of Doors
1
Sliding Glass Door
No
Number of Slideouts
1
Power Retractable Slideout
Yes
Number of Awnings
1
Awning Length (ft/m)
16 / 4.9
Power Retractable Awning
Yes
Screened Room
No
Leveling Jack Type
Front Power / Rear Power
Power Retractable Entry Steps
Standard
Sky Light
Standard
Roof Vents
Standard
Battery Cover
Standard
Exterior Window Shade / Cover
Standard
Exterior Shower
Standard
Slideout Awning
Standard
Voltage Meter
Standard
Fresh Water Holding Tank Gauge
Standard
Gray Water Holding Tank Gauge
Standard
Black Water Holding Tank Gauge
Standard
Water Pump Power Display
Standard
Propane Tank Gauge
Standard
Generic Type (Primary)
Class C
Manufacturer Country
USA
Introduction Year
2016
Regional Availability
All Regions
Display Name
Isata 5 Series 30FW
Year
2022
Make
Dynamax
MSRP
$236,158.00
Kitchen / Living Area Flooring Type
Vinyl
Kitchen Table Configuration
Bench Seats
Kitchen Location
Center
Living Area Location
Front
Number Of Oven Burners
3
Overhead Fan
Yes
Layout
Oven / Stove
Convection
Yes
Refrigerator Size
Full-Size
Refrigerator Power Mode
Electric
Sink Cover / Cutting Boards
Standard
Number Of Sofas
1
Sofa Material
Vinyl
Reclining Sofa
No
Max Sleeping Count
8
Number Of Bunk Beds
0
Number Of Double Beds
1
Number Of Full Size Beds
0
Number Of Queen Size Beds
1
Number Of King Size Beds
0
Number Of Convertible / Sofa Beds
2
Master Bedroom Flooring Type
Vinyl
Master Bedroom Door Style
Curtain
Full Size Master Bedroom Closet
Yes
Master Bedroom Mirror Doors
Yes
Master Bedroom Shades / Curtains
Yes
Master Bedroom Location
Rear
Bunkhouse
No
Bed Spreads
Standard
Number Of Bathrooms
1
Bathroom Flooring Type
Vinyl
Bathroom Location
Rear
Toilet Type
Porcelain
Toilet Location
Rear
Door Type
Curtain
Shower Location
Rear
Bathroom Sink Location
Rear
Bathroom Medicine Cabinet Location
Rear
Bathroom Mirror Location
Rear
Bathroom Vent / Fan System Location
Rear
Sink / Faucet
Standard
Power Vent Fan
Standard
Battery Power Converter
Yes
Air Conditioning Prewiring
Yes
Cable Prewiring
Yes
Phone Prewiring
No
Heat Prewiring
Yes
TV Antenna Prewiring
Yes
Satellite Prewiring
Yes
Washer / Dryer Prewiring
No
Back-Up Camera
Yes
Solar
Yes
Exterior Plugs
Standard
Ground Fault Plugs
Standard
Solar Battery Charger
Standard
Generator
Standard
Smoke Detector
Standard
Carbon Monoxide Detector
Standard
Propane Alarm
Standard
Emergency Exit (s)
Standard
Number Of Emergency Exits
1
Rear Hitch Type
Receiver
Air Conditioning Type
Automatic
Heater Type
Automatic
Water Heater Tank Capacity (g/l)
0 / 0
Water Heater Pump Power Mode
Propane
Tankless Water Heater
Yes
Freeze Proof Insulation
Standard
Satellite
Yes
Number Of Radios
1
Speaker Location (s)
Interior / Exterior
Number Of Discs
1
CB Radio
Standard
DVD Player
Standard
Number Of Televisions
3
Exterior Entertainment System
Standard
Retractable Roof Antenna
Standard
Bluetooth® Audio
Yes
Mobile App Instrumentation
Yes
Wi-Fi Capable
Yes
Exterior Flood Lights
Standard
Cruise Control
Standard
Power Windows
Standard
Rear Video Backup Camera
Standard
Paint
Standard
Wallpaper
Yes
Interior Wood Finish
Yes
Curtains / Shades
Standard
Basic Warranty (Months)
12
Structure Warranty (Months/Miles)
12 / 12000
Powertrain Warranty (Kilometers)
160934
Chassis Warranty (Months/Miles)
36 / 36000
Driveline Type
4X2
